Mars Time Domain Electromagnetic Sounder (1 of 2)

Caption

These images show the concept for a flight version of the Mars Time Domain Electromagnetic Sounder (MTDEM), which uses induction to detect groundwater up to 5 km deep. These illustrations show the MTDEM launcher in its stowed (cruise) and deployed (landed) configurations; spooling projectiles are then ejected using compressed gas, forming a large wire loop on the planet's surface.

Credit

Credit to SwRI and Ball Aerospace. Video and graphics provided by Ball Aerospace.

Usage Restrictions

The image may be used by the public and the media for educational and informational purposes only.
