Figure 5. Characteristics of the interlaced corrugated structure

Caption

The interlacing joints allow strip sliding so that the multi-layer folded structure can still be wound smoothly around the hub, while the dense constraints between strips enhance cross-sectional stability and ensure high strength when the corrugated structure is deployed.

Credit

© Science Robotics, originally published in Science Robotics
