Structure and characterization of the gate-tunable flexible photodetector based on Gr/MoS2/SWCNT asymmetric heterostructure. (IMAGE)

Aerospace Information Research Institute, Chinese Academy of Sciences

Structure and characterization of the gate-tunable flexible photodetector based on Gr/MoS2/SWCNT asymmetric heterostructure.

Caption

Structure and characterization of the gate-tunable flexible photodetector based on Gr/MoS2/SWCNT asymmetric heterostructure. a Schematic of the 3D structure of the flexible photodetector based on Gr/MoS2/SWCNT. b Schematic of the working principle of the flexible photodetector based on Gr/MoS2/SWCNT. c Photograph of the flexible photodetector based on PET substrate. d SEM image of the flexible photodetector based on Gr/MoS2/SWCNT. e Comparison of Raman spectra of the flexible photodetector based on Gr/MoS2/SWCNT and the original MoS2 film. f Comparison enlarged diagram of MoS2 peak.

Credit

Microsystems & Nanoengineering

Usage Restrictions

Credit must be given to the creator. Only noncommercial uses of the work are permitted. No derivatives or adaptations of the work are permitted.

License

CC BY-NC-ND
