BSPDN analysis with n-TSVs. (IMAGE)

Higher Education Press

BSPDN analysis with n-TSVs.

Caption

(a) Integration schematic of an n-TSV in BSPDN architecture; (b) high-AR n-TSV array configuration; (c) calculated thermal stress mappings in n-TSVs with (i) vertical and (ii) tapered sidewalls. Contour scale: 0–500 MPa. BPR: buried power rail.

Credit

Biao Wang, Feifeng Huang et al.

Usage Restrictions

Credit must be given to the creator. Only noncommercial uses of the work are permitted. No derivatives or adaptations of the work are permitted.

License

CC BY-NC-ND
