Image showing the nodes and lines of a prototypical power grid (IMAGE)

American Institute of Physics

Image showing the nodes and lines of a prototypical power grid

Caption

Image showing the nodes and lines of a prototypical power grid. It has a total of 400 nodes, of which 340 are nodes with only consumption, while the remaining 60 have consumption and generation. The nodes are interconnected by 617 lines.

Credit

Image created by B. Carreras using Mathematica
