The Janus/Epimetheus Ring

Caption

A new diffuse ring, coincident with the orbits of Saturn's moons Janus and Epimetheus, has been revealed in ultra-high phase angle views from Cassini. The new ring is visible in this image (marked by a cross) outside the overexposed main rings and interior to the G and E rings. The G ring has a sharp inner boundary; the E ring is extremely broad and arcs across the upper and lower portions of the scene. While it is not unexpected that impact events on Janus and Epimetheus might kick particles off the moons' surfaces and inject them into Saturn orbit, it is, however, surprising that a well-defined structure exists at this location. The view looks down from about 15 degrees above the unilluminated side of the rings. Some faint spokes can also be spotted in the main rings, made visible by sunlight diffusing through the B ring. The image was taken in visible light with the Cassini spacecraft wide-angle camera on Sept. 15 at a distance of approximately 2.2 million kilometers (1.3 million miles) from Saturn and at a Sun-Saturn-spacecraft angle of almost 179 degrees. Image scale is 130 kilometers (81 miles) per pixel. The Cassini-Huygens mission is a cooperative project of NASA, the European Space Agency and the Italian Space Agency. The Jet Propulsion Laboratory, a division of the California Institute of Technology in Pasadena, manages the Cassini-Huygens mission for NASA's Science Mission Directorate, Washington, D.C. The imaging team consists of scientists from the U.S., England, France and Germany. The imaging operations center and team lead (Dr. C. Porco) are based at the Space Science Institute in Boulder, Colo. For more information about the Cassini-Huygens mission, visit http://saturn.jpl.nasa.gov and the Cassini imaging team home page, http://ciclops.org. [A version without the cross that marks the new ring is also available.] Credit: NASA/JPL/Space Science InstituteNASA/JPL/Space Science Institute Released: September 19, 2006 (PIA 08322)

Credit

Credit: NASA/JPL/Space Science Institute NASA/JPL/Space Science Institute

Usage Restrictions

Appropriate credit (as listed in the image caption) is requested.
