Map showing crystallographic orientation (IMAGE)

American Institute of Physics

Map showing crystallographic orientation

Caption

A map showing crystallographic orientation of a region that originally contained a void, which was then subjected to a second shock loading (the shock wave passed from the bottom to the top of the image). The void has been recompacted with enough energy to not only reach a fully dense state, but drive recrystallization at the interface, as demonstrated by the thin band of very small grains.

Credit

David Jones

Usage Restrictions

Journalists may use this image only with appropriate credit.
