Photograph of a Newly Developed in Vivo Real-Time Monitoring System (IMAGE)
Caption
The newly developed system combines a free-movable stage and PESI-tandem mass spectrometer. The stage is set in front of the mass spectrometer. PESI uses an extremely thin (acupuncture) needle, which achieves low-invasive sampling.
Credit
Kei Zaitsu
