Complex Dewetting Scenarios of Ultrathin Silicon Films for Large-Scale Nanoarchitectures (1 of 7)

Caption

Scanning electron microscope images of complex nano-architectures based on silicon particles. These structures are obtained via solid-state dewetting of an ultra-thin, flat layer of silicon on silicon dioxide. Before dewetting the thin film was patterned with simple shapes in order to guide the self-assembly of the complex nano-architectures. This material relates to a paper that appeared in the 10 Nov. 2017, issue of Science Advances, published by AAAS. The paper, by M. Naffouti at Université de Toulon in Marseille, France, and colleagues was titled, "Complex dewetting scenarios of ultrathin silicon films for large-scale nanoarchitectures."

Credit

[Credit: Luc Favre, Thomas David, and Jean-Benoit Claude]
