Two Dermascope Implementations

Caption

Fig. 1 Two dermascope implementations. The USB-camera-based PMSI and PWLI dermascope is shown in (a) and (b). (a) Various components of the handheld imaging module (the USB camera is hidden behind the imaging polarizer) and (b) the imaging module paired with the smartphone camera. The smartphone-camera-based PMSI and PWLI dermascope is shown in (c), (d), and (e). (c) The smartphone-based system's side opposite the smartphone screen with the imaging annulus removed, where the LED PCB and smartphone camera are visible and other components are highlighted; (d) the system with the imaging annulus attached; and (e) the smartphone installed in the dermascope.
