Blade View (IMAGE)

Southwest Research Institute

Blade View

Caption

DARWIN helps the user to visualize and manipulate a three-dimensional component model, identifying the location where a crack might initiate, slicing the model along the plane where this crack is most likely to grow, and determining the stresses on this plane that will govern the growth rate of the crack.

Credit

Blue Planet Studio

Usage Restrictions

Images/videos may be used by the media and the public for educational and informational purposes only
