Mysterious Charge Transport Unraveled

Caption

This is an Atomic Force Microscopy image of island growth in between two electrodes (left and right) of the SAMFET. The self-assembled monolayer islands, in the middle of the figure, conduct charges. In this case, no path is formed between the two electrodes and therefore current cannot flow. The height of the molecules is 3 nanometers; the length of the gap between the electrodes (i.e. the transistor channel length) is 5 microns.

Credit

Simon Mathijssen

Usage Restrictions

The image may only be used with appropriate caption and credit.
