33-Channel SQUID

Caption

This is a photograph of a 33-channel SQUID multiplexer chip (20 mm x 4 mm) along with its microwave response showing the associated resonances. Multiple chips are daisy-chained together to achieve larger multiplexing factors.

Credit

J.A.B. Mates, University of Colorado, Boulder
