High-Energy Diffraction Microscopy Experiments

Caption

This setup is used for high-energy diffraction microscopy experiments -- it involves a rotational and axial motion system load frame insert in a conventional load frame along with near-field and far-field detectors. The loading axis is vertical, and the specimen and specimen grips rotate around the loading axis while the rest of the setup remains stationary.
