Graphic image

Caption

Temperature distribution (°C) and thermal lesions created in cardiac tissue with the catheter in the parallel orientation by a standard ablation protocol of 20?W-45?s (A) and 30?W-30?s (B), and also a HP-SD ablation protocol of 70?W-7?s (C) and 90?W-4?s (D).

Credit

Sergi Coderch

Usage Restrictions

None
