Tracking Invasive Surgical Tools

Caption

This graphic illustrates a surgical tool in a human lung. The blue curve corresponds to what we expect the device to do. The green curve represents what would happen in a real procedure were some perturbations introduced. The red-dots represent the estimated shape based on where the new x-ray algorithm says the surgical tool actually is.

Credit

Edgar Lobaton, North Carolina State University

Usage Restrictions

Image credit must be given.
