Dip-Pen Nanolithography (IMAGE)

DOE/Lawrence Berkeley National Laboratory

Dip-Pen Nanolithography

Caption

Thermal dip-pen nanolithography turns the tip of scanning probe microscope into a tiny soldering iron that can be used to draw chemical patterns as small as 20 nanometers on surfaces.

Credit

Image courtesy of DeYoreo, et. al

Usage Restrictions

None
