Results of Scanning X-Ray Microdiffraction

Caption

This image shows the results of scanning X-ray microdiffraction (μSXRD) with submicron spatial resolution. Laue diffraction (a) from an unconstrained Sb2S3 single crystal (top) and laser fabricated RLS crystal Sb2S3 (bottom). Magnified images (b) of selected reflection (852) extracted from Laue patterns (a, bottom) obtained for different points of the RLS crystal (c).

Credit

D. Savytskii, H. Jain, N. Tamura & V. Dierolf
