Figure 1

Caption

Image of an unregistered terminal (right) and visualization screen (left) of real-time visualization technology for wireless environment. By analyzing the information from the sensor installed in the yellow circle in the left figure, the radio wave reach range is indicated by the intensity and color, and the position of the unregistered terminal is specified. Axis X, Y: Distance(m), Value above the circle: RSSI?Received Signal Strength Indicator)(dBm)
