Figure 1. Microscopic nanomechanics measurement method (IMAGE)

Japan Advanced Institute of Science and Technology

Figure 1. Microscopic nanomechanics measurement method

Caption

(left) Schematic illustration of the technique. The stiffness of nanomaterials such as platinum (Pt) atomic chains can be measured using a length-extension resonator (LER) made with a quartz crystal. The atomic structure of the chain can be observed using a transmission electron microscope (TEM). We found that the atomic bond strength in the Pt monoatomic chains is 25 N/m, which is higher than the bulk value (20 N/m). (right) Experimental and simulated TEM images of a monoatomic Pt chain and time evolution of its electrical conductance and stiffness during stretching. The maximum strain was 24% on average.

Credit

Yoshifumi Oshima

Usage Restrictions

None
