Figure 1. Design of the Layered Three-Valued Memory Cell (IMAGE)

_Tokyo Institute of Technology

Figure 1. Design of the Layered Three-Valued Memory Cell

Caption

The stacked layers in the proposed memory device form a mini-battery that can be quickly and efficiently switched between three different voltage states (0.95 V, 1.35 V, and 1.80 V).

Credit

ACS Applied Materials and Interfaces
