Schematic illustration of the meta-optical fiber endoscope (MOFIE). (IMAGE)

Light Publishing Center, Changchun Institute of Optics, Fine Mechanics And Physics, CAS

Schematic illustration of the meta-optical fiber endoscope (MOFIE).

Caption

A meta-optic is optimised for integration with the coherent fiber bundle, whereas the individual fiber cores are taken as the imaging limitation. The MOFIE achieves a reduced tip length while maintaining a wide field of view of 22.5° and a large depth of field exceeding 30 mm, compared with a traditional GRIN lens.

Credit

by Johannes E. Fröch, Luocheng Huang, Quentin A.A. Tanguy, Shane Colburn, Alan Zhan, Andrea Ravagli, Eric J. Seibel, Karl Böhringer, Arka Majumdar

Usage Restrictions

Credit must be given to the creator.

License

CC BY
