Figure 3 (IMAGE)

Advanced Institute for Materials Research (AIMR), Tohoku University

Figure 3

Caption

Representative metallic surfaces for the growth of carbon nanostructures. (a) pure Cu(111), (b) Cr(110, and (c) Ti(001) surface. Below each surface, High resolution transmission electron microscopy (HRTEM) images and selected area electron diffraction (SAED) images of carbon nanostructures prepared by magnetron sputtering deposition are provided. (d) The number of sp2-C as a function of deposited carbon atoms on different metal substrates and e O-contaminated Cu(111).

Credit

Hao Li et al.
