a The three-dimensional CST target chamber model. b c d The left view and e f g the main view of the CST model for the temporal evolution of EMPs. (IMAGE)

Nuclear Science and Techniques

a The three-dimensional CST target chamber model. b c d The left view and e f g the main view of the CST model for the temporal evolution of EMPs.

Caption

This figure presents a series of 3D simulations using CST Particle Studio to model the temporal evolution of electromagnetic pulses (EMPs) generated after electrons escape from a nitrogen gas jet target.

Credit

Zhi-Gang Deng

Usage Restrictions

Credit must be given to the creator. Only noncommercial uses of the work are permitted.

License

CC BY-NC
