3D rendering of MARTINIS (IMAGE)
Caption
3D model representation of the MARTINIS and photo of actual system inside a 70 cm long cylindrical plexiglass housing. 1) Raspberry Pi HQ camera with 16 mm telephoto lens for Raspberry Pi. 2) Emission filter, Blue-UV blocker. 3) Raspberry Pi 4 model B 4 GB. 4) 395 nm LED. 5) 5 mm white LED. 6) Stepper Motor (Rotational movement). 7) Stepper motor (Vertical movement). 8) Resistor for 395 nm LED. 9) 5 V relay. 10)10 mm Fan. 11) End-stop trigger. 12) Ball bearing 13) Gear ring for rotational movement. 14) Step-Down voltage regulator. 15) 2x A4988 Stepper drivers. 16) Gear for rotational movement. 17) Temperature/Humidity sensor. 18) Time-of-Flight distance sensor.
Credit
Martin Reinhard Rasmussen. Sensors and Actuators: B. Chemical
Usage Restrictions
Credit must be given to the creator. Only noncommercial uses of the work are permitted. No derivatives or adaptations of the work are permitted.
License
CC BY-NC-ND
