Figure 2 | High power conversion efficiency Platicon microcomb. (IMAGE)

Light Publishing Center, Changchun Institute of Optics, Fine Mechanics And Physics, CAS

Figure 2 | High power conversion efficiency Platicon microcomb.

Caption

Figure 2 | High power conversion efficiency Platicon microcomb. (a) Dispersion characterization of silicon nitride chip. (b) The optical spectral evolution of the platicon microcomb. (c) Numerical simulation and experimental comb spectrum at stage 2 and 4.

Credit

Wenting Wang, Hao Liu et al.

Usage Restrictions

Credit must be given to the creator.

License

CC BY
