Schematic view of the experimental setup (IMAGE)
Caption
Our detection system consists of a TPC and a silicon detector array. It was installed in the detector chamber filled with counting gas.A large-area Kapton foil with a thickness of 5 µm and an area of 7×21cm2 was used to separate the gas in the detector chamber from the reaction chamber. The Kapton foil was coated with around 100 nm aluminum to prevent from charge accumulation and shield silicon detec tors from the light coming from the beam spot on the carbon target
Credit
Shuo Wang
Usage Restrictions
Credit must be given to the creator. Only noncommercial uses of the work are permitted.
License
CC BY-NC
