Illustration of the KATRIN experiment

Caption

The KATRIN experiment. From left to right, the rear wall and electron gun, the windowless gaseous tritium source, the transport and pumping section, the pre- and main spectrometers, and the focal-plane detector in which the electrons are detected and counted.

Credit

KATRIN collaboration
