Figure 2. High-brightness, ultrathin, and flexible thermosensing patches for in situ temperature monitoring. (IMAGE)

Light Publishing Center, Changchun Institute of Optics, Fine Mechanics And Physics, CAS

Figure 2. High-brightness, ultrathin, and flexible thermosensing patches for in situ temperature monitoring.

Caption

Figure 2. High-brightness, ultrathin, and flexible thermosensing patches for in situ temperature monitoring. a Schematic of the real-scene monitoring under 980 nm excitation. b Photographs showing the lateral size, thickness, and bendability of the high-brightness flexible ultrathin microscale thermosensing patches (HFMTPs), demonstrating conformal contact with both flat and curved substrates. c Images of the ultra-bright luminescence of the HFMTP under 980 nm irradiation and demonstration of in situ temperature measurement. d LIR-derived temperature fluctuations under distinct operating conditions: argon flow (Ar-NoStir), vacuum (Vac-NoStir), argon flow with 20 rpm stirring (Ar-Stir), vacuum with 20 rpm stirring (Vac-Stir), and argon flow with 100 rpm stirring (Ar-FastStir). The temperature controller remained active throughout. e Statistical analysis of the deviations between LIR-derived and thermocouple-measured temperatures. f Repeatability of the LIR readout over five heating and cooling cycles between 373 and 423 K.

Credit

Zuoling Fu et al.

Usage Restrictions

Credit must be given to the creator.

License

CC BY
