Figure 2 (IMAGE)

Advanced Institute for Materials Research (AIMR), Tohoku University

Figure 2

Caption

Electrochemical performance of Mg and Mg alloy anodes with MBN. (a) Cyclic voltammetry curves of Mg and Mg alloy|MBN|SS asymmetric cells. (b) Galvanostatic cycling of symmetric cells at current densities from 0.1 to 1 mA cm⁻². (c) Long-term cycling curves of Mg and five alloy anodes with MBN in symmetric cells at 0.1 mA cm⁻². Insets show detailed stripping/plating voltage plateaus at selected durations.

Credit

Qian Wang et al.
