Figure 3 (IMAGE)

Tohoku University

Figure 3

Caption

Comparison of spin wave transmission intensity between the new waveguide and the conventional waveguide. Spin wave intensity is plotted against the propagation length along the waveguide. Black dots represent the invented new waveguide, and red dots represent the conventional ridge-type waveguide. The vertical axis is on a logarithmic scale. Near the output end (propagation length of 14 mm), the spin wave intensity in the new waveguide is over 5,000 times greater than that of the conventional waveguide, demonstrating that spin waves can propagate even through a Z-shaped bent path.

Credit

Taichi Goto

Usage Restrictions

Credit must be given to the creator.

License

CC BY
