Study Infographic (IMAGE)

University of Malaga

Study Infographic

Caption

The left image shows optical microscope of the chip, which is 1 cm wide approximately, and includes about ten sensors. The right image shows electronic microscope of the infrastructure used to inject light into the chip, which is 10 micron wide

Credit

University of Malaga

Usage Restrictions

None
