Solid-State Nanopore (IMAGE)

Technical University of Munich (TUM)

Solid-State Nanopore

Caption

This transmission electron micrograph shows a solid-state nanopore: The white circle in the middle of the picture. The otherwise patchy-looking structure results from the polycrystalline nature of a gold film that was evaporated onto the silicon nitride membrane (which cannot be seen).

Credit

Rant group, TU Muenchen Copyright TU Muenchen

Usage Restrictions

This image may be freely used, with copyright noted, in news coverage of TU Muenchen.
