Imaging of MIID integrated with polarization multiplexed dual phase (PMDP) metalens array.

Caption

Imaging of MIID integrated with polarization multiplexed dual phase (PMDP) metalens array. (a) Phase distribution of PMDP metalens in x-y plane. The blue and red squares denote the phase distribution for LCP and RCP metalens regions respectively. The corresponding dashed boxes demonstrate the limited FOV. (b) Optical microscope image of a PMDP metalens with size 200 μm. (c) Photograph of the fabricated 6×6 PMDP metalens array. (d) Photograph of the prototype of MIID in size about 3.5 cm × 3 cm × 2.5 cm. (f) Stitched image of the USAF 1951 resolution chart.

Credit

Xu et al., doi 10.1117/1.AP.2.6.066004
