How NIST Uses Blue Light to See Through Fire

Caption

Graphic illustrating the NIST narrow-spectrum illumination method for imaging through fire. Blue LED light is directed through a gas fire, reflects off the target object behind the flames and is captured by a camera after passing through an optical filter. This reduces the observed intensity of the flame by 10,000-fold and yields highly detailed images.

Credit

Graphic created by N. Hanacek/NIST based on a concept by M. Hoehler/NIST

Usage Restrictions

None
