Individual Molecules Under Strain (IMAGE)

National Institute of Standards and Technology (NIST)

Individual Molecules Under Strain

Caption

In this image, 200 nanometers (nm, billionths of a meter) square image, the size and direction of the arrows show the average local alignment of individual fluorescent molecules as a result of the strain produced by a square punch (the size of the gray dotted line) driven into the material, and then pulled out at an angle towards the top of the image.

Credit

NIST

Usage Restrictions

Please credit NIST when using this image.
