ALS-U Rendering (IMAGE)

DOE/Lawrence Berkeley National Laboratory

ALS-U Rendering

Caption

This rendering shows the existing equipment at Berkeley Lab's Advanced Light Source (lower right) that forms the storage ring where accelerated electrons give off energy in the form of light. A planned upgrade, ALS-U (left and upper right), would replace this storage ring with a denser array of magnets, known as an MBA lattice, that would produce far brighter, steadier beams of so-called "soft" X-ray light. A unique secondary ring along the ALS's inner wall, called an "accumulator" ring, would rapidly replenish the energy in the main ring.

Credit

Berkeley Lab
