Aircraft Fire Dynamics Simulation

Caption

NIST researchers used the Fire Dynamics Simulator (FDS) to model the temperatures of smoke throughout the overhead compartment of an airliner. A 3D rendering of FDS's output shows a slice of smoke rising from a gas burner placed at the front of the compartment, with colors indicating temperature from hot (red) to cold (blue).

Credit

NIST

Usage Restrictions

None
