PTB SQUID Sensor Chip Mounted on a Chip Carrier (IMAGE)

Physikalisch-Technische Bundesanstalt (PTB)

PTB SQUID Sensor Chip Mounted on a Chip Carrier

Caption

PTB SQUID sensor chip (3 mm x 3 mm) is mounted on a chip carrier. The SQUID chips are manufactured similarly to a computer chip in the semiconductor industry.

Credit

Photo: PTB

Usage Restrictions

None
