New Miniaturized Device for Lab-on-a-Chip Separations

Caption

Core of the new NIST miniature GEMBE chemical separation device (above left) is a machined acrylic block, shown with a quarter for scale. Eight sample resevoirs for multiplexed separations form a ring around the central buffer solution port. (Smaller holes are for assembly screws.) At right: prototype in use.

Credit

NIST
