Graphene Reinforcement in High Res (IMAGE)

University of Arizona College of Engineering

Graphene Reinforcement in High Res

Caption

High resolution SEM image after colloidal processing indicating partially exfoliated GPL mixed with well-dispersed Si3N4 particles. The images clearly indicate GPL decorated with Si3N4 particles; the Si3Nk4 particles are well-dispersed throughout the surface area of the sheets.

Credit

ACS Publications/UA Engineering

Usage Restrictions

Usage granted only with attribution to ACS Publications/UA Engineering
