ESPI Images of the Singing Bowl Showing the (2,0) Mode

Caption

ESPI images of the singing bowl showing the (2,0) mode. The lines represent contours of equal displacement. The frequency of oscillation is shown in the upper left corner (in Hz). The two images are of the same modal structure, rotated by 90 degrees. A slight asymmetry in the bowl breaks the modal degeneracy by 0.6 Hz.

Credit

C. Keefer and S. Collin/Rollins

Usage Restrictions

This image may be used only with appropriate caption and credit.
