Figure 3 (IMAGE)

DGIST (Daegu Gyeongbuk Institute of Science and Technology)

Figure 3

Caption

Device-level integration of the proposed electrode composite. a) Schematic illustrations and b) optical images of wireless electrophysiology (EP) monitoring systems integrated with soft, folded magnetic electrode composites. Optical images of the device on the body and associated captured EP data: c) electrocardiogram (ECG), d) electromyogram (EMG), e) electrooculogram (EOG), and f) electroencephalogram (EEG). Scare bars are 10 cm in (c,d) and 5 cm (e,f).

Credit

DGIST
