Electron Microscope Pictures of the Micro-spectrometer

Caption

The upper picture shows the entire device; the large yellow areas are contact pads. The lower picture shows the perforated membrane, and the inlay zooms in on the photonic crystal cavity (the area without holes).

Credit

Eindhoven University of Technology.
