The architecture of the silicon photonic MEMS switch with gap-adjustable directional couplers. (IMAGE)

SPIE--International Society for Optics and Photonics

The architecture of the silicon photonic MEMS switch with gap-adjustable directional couplers.

Caption

The architecture of the silicon photonic MEMS switch with gap-adjustable directional couplers. Light is coupled to the chip using the grating couplers. There are two pairs of the directional couplers and one comb-drive actuator per unit cell. The light paths on the chip are controlled by changing the gap spacing of each directional coupler.
