Transmission Electron Microscope Image of Carbon Nanopot Fiber

Caption

The black arrow indicates the end of the opening of carbon nanopot. A structural schematic of the carbon nanopot showing hydroxyl groups bonded to the edges of the graphene layers near the closed end of the nanopot is also indicated (not to scale). Journal of Materials Research, 31((1): 117-126, 14-Jan-2016, doi:10.1557/jmr.2015.389. Copyright: Materials Research Society

Credit

Dr. Eng. Hiroyuki Yokoi
