Enhanced Illustration of US Patent 10,197,365

Caption

This is an enhanced illustration of US Patent 10,197,365, showing the net under the proximity detector, which detonates a small charge springing the warhead apart and spreading the net out at a distance of six to nine meters from the target.

Credit

Troy Carter/TechLink

Usage Restrictions

None
