Holographic Imaging Mode

Caption

In holographic imaging mode, the electron beam encompasses the whole sample, forming a reference wave and an object wave. These waves then interfere with each other to form a hologram, which is recorded by a detector.

Credit

Modified from Martin Cheung, Hidehito Adaniya, Cathal Cassidy, Masao Yamashita, Tsumoru Shintake. Low-energy in-line electron holographic imaging of vitreous ice-embedded small biomolecules using a modified scanning electron microscope. Ultramicroscopy, 209 (2020) 112883, Fig 2. Copyright 2020 with permission from Elsevier.

Usage Restrictions

Permission from Elsevier required
