2 Infrared Beams, 1 Atomic Force Microscope

Caption

Infrared light (pink) produced by Berkeley Lab's Advanced Light Source synchrotron (upper left) and a conventional laser (middle left) is combined and focused on the tip of an atomic force microscope (gray, lower right), where it is used to measure nanoscale details in a crystal sample (dark red).

Credit

Berkeley Lab, CU-Boulder

Usage Restrictions

None
