Diamond Anvil Cell (IMAGE)

European Synchrotron Radiation Facility

Diamond Anvil Cell

Caption

This illustration depicts a diamond anvil cell which allows to compress microscopic pieces of material to pressures of 3 Mbar and more. Laser pulses (black arrows) then heat the sample and an X-ray beam (orange) passes through the cell to probe the states of matter at these extreme conditions.

Credit

ESRF/Format Editions

Usage Restrictions

None
